InLine PoE+ Gigabit Networking Switch 5 Port (4x PoE+),11" (19" brackets incl.), Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting
Operating temperature (T-T): 0 - 40 °CMaximum data transfer rate: 1000 Mbit/sBasic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)Basic switching RJ-45 Ethernet ports quantity: 5Storage relative humidity (H-H): 5 - 95%Height: 44.5 mm
Specifikacije
- Operating temperature (T-T)
- 0 - 40 °C
- Maximum data transfer rate
- 1000 Mbit/s
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- Basic switching RJ-45 Ethernet ports quantity
- 5
- Storage relative humidity (H-H)
- 5 - 95%
Opis
Description
The InLine® Gigabit Networking Switch 5 Port (4x PoE+), 1 Gbps, 11" (19" brackets included), metal without fan provides a fast network connection and PoE+ support on 4 of the 5 ports. All 5x 10/100/1000Mbps Auto-Negotiation RJ45 ports support Auto MDI/MDIX function. The switch is easy to use and a high-performance upgrade of your old network to a 1000Mbps Gigabit network and to power PoE-enabled devices such as IP cameras, IP phones, access points, etc. via the connected patch cable.
Features
Complies with IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3af, IEEE802.3at standards
Supports up to 25.5W power per port (up to 75W over all ports)
Supports up to 1K MAC adresses
Supports IEEE802.3x flow control for full duplex mode and backpressure for half duplex mode
Supports PoE devices according to IEEE802.3af and IEEE802.3at
LED indicators for monitoring power, link/activity and PoE
Specification
Chipset: RTL8367N
Standards: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x, IEEE802.3af, IEEE802.3at
Network Media (Cable): 10Base-T: UTP cable Cat. 3, 4, 5 (max. 100m) / 100Base-TX: UTP cable Cat. 5, 5e (max. 100m) / 1000Base-T: UTP cable Cat. 5e, 6 (max. 100m)
Number of ports: 5x 10/100/1000Mbps Auto-Negotiation ports
LED indicators: 10/100/1000M: Link/ACT // PoE: PoE, PoE MAX // Other: Power
Transfer method: Store-and-forward
Switching capacity: 10G
MAC address learning: Automatically learning, automatically update of the 1K table
Frame Filtering and Forward rate: 10Mbps: 14880pps // 100Mbps: 148800pps // 1000Mbps: 1488000pps
Dimensions (W x D x H): 280x179x44,5mm (11" metal case)
Environment: Operating temperature: 0°C - 40°C // Storage temperature: -10°C - 70°C // Operating humidity: 10%~90% non-condensing // Storage humidity: 5%~95% non-condensing
The InLine® Gigabit Networking Switch 5 Port (4x PoE+), 1 Gbps, 11" (19" brackets included), metal without fan provides a fast network connection and PoE+ support on 4 of the 5 ports. All 5x 10/100/1000Mbps Auto-Negotiation RJ45 ports support Auto MDI/MDIX function. The switch is easy to use and a high-performance upgrade of your old network to a 1000Mbps Gigabit network and to power PoE-enabled devices such as IP cameras, IP phones, access points, etc. via the connected patch cable.
Features
Complies with IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3af, IEEE802.3at standards
Supports up to 25.5W power per port (up to 75W over all ports)
Supports up to 1K MAC adresses
Supports IEEE802.3x flow control for full duplex mode and backpressure for half duplex mode
Supports PoE devices according to IEEE802.3af and IEEE802.3at
LED indicators for monitoring power, link/activity and PoE
Specification
Chipset: RTL8367N
Standards: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x, IEEE802.3af, IEEE802.3at
Network Media (Cable): 10Base-T: UTP cable Cat. 3, 4, 5 (max. 100m) / 100Base-TX: UTP cable Cat. 5, 5e (max. 100m) / 1000Base-T: UTP cable Cat. 5e, 6 (max. 100m)
Number of ports: 5x 10/100/1000Mbps Auto-Negotiation ports
LED indicators: 10/100/1000M: Link/ACT // PoE: PoE, PoE MAX // Other: Power
Transfer method: Store-and-forward
Switching capacity: 10G
MAC address learning: Automatically learning, automatically update of the 1K table
Frame Filtering and Forward rate: 10Mbps: 14880pps // 100Mbps: 148800pps // 1000Mbps: 1488000pps
Dimensions (W x D x H): 280x179x44,5mm (11" metal case)
Environment: Operating temperature: 0°C - 40°C // Storage temperature: -10°C - 70°C // Operating humidity: 10%~90% non-condensing // Storage humidity: 5%~95% non-condensing
